Resilient Acoustic Stud
Increase the net internal area and profitability of your next apartment, hotel or student accommodation project.
Siniat ResilienT Acoustic Stud (RAS)
UNLOCK VALUE IN YOUR PARTITIONS WITH RAS
Available in two sizes, the Resilient Acoustic Stud (RAS) range is a game-changing innovation for party wall and external corridor wall partitions. It is a simple C-stud which has an inbuilt acoustic material preventing airborne and impact sound from passing through dividing walls.
RAS 90 can deliver the acoustic requirements of Approved Document E, whilst reducing the partition width by 50 mm, releasing significant development value for clients.
RAS 90
RAS 90
To achieve 45 DnTw + CTR: suitable for multi-residential, apartments, student accommodation, hotels and change of use.
RAS 70
RAS 70
To achieve 43 DnTw + CTR: suitable for care homes, student accommodation, hotels and change of use.
See the benefits
USE 50% LESS METAL MATERIAL
PROTECT ACOUSTIC INTEGRITY
INCREASE NET INTERNAL SPACE
REDUCE INSTALLATION TIME BY 50%
HOW MUCH VALUE CAN YOU RELEASE IN YOUR NEXT PROJECT?
Compare the installation benefits of a single frame (RAS) v twin frame partition
| Twin frame partition (200mm) | RAS partition (150mm) | % Difference | |
| Measuring & cutting | 20 mins | 10 mins | -20% |
| Floor tracks | 10.8 mins | 5.4 mins | -11% |
| Studs | 56.16 mins | 28.08 mins | -55% |
| Head track | 14.4 mins | 7.2 mins | -14% |
| Total frame | 101.36 mins | 50.68 | -50% |
LEARN MORE
LEARN MORE
DISCOVER MORE FROM THIS SHORT VIDEO
210 essential RAS systems
Suspended MF System PGC 002
1x Siniat Creason C10no8, Siniat MF Ceiling Channels at Max 450mm centres, Siniat Connecting Clips, 50mm glass mineral wool and 600mm void, Any suitable soffit
Mass Barrier Ceilings RCC 060
1x 12.5mm Siniat dB Board, 1x 12.5mm Siniat dB Board, Siniat Ceiling Channels at max. 450mm centres Heavy Duty Primary channels UT52/Y at 900mm Centres, Phonissimo Acoustic Hangers as 1200mm Centres, 100mm 10.5kg/m3 glass mineral wool, Any suitable soffit
Mass Barrier Ceilings RCC 061
Suspended ceiling system to create a void beneath a soffit for services, acoustic performance or fire protection
Direct-to-Timber System RTC 061
1x 15mm Siniat Standard Board,Single Siniat Resilient Bar at max. 450mm centres,47mm x 200mm joists at 450mm centres,22mm tongue and grooved chipboard
Direct-to-Timber System RTC 004
1x 12.5mm Siniat Standard Board,1x 12.5mm Siniat Standard Board,100mm 10.5kg/m3 glass mineral wool,47mm x 200mm joists at 600mm centres,22mm tongue and grooved chipboard
Direct-to-Timber System RTC 065
1x 12.5mm Siniat Standard Board,100mm 10.5kg/m3 glass mineral wool,47mm x 200mm joists at 400mm centres with noggins,22mm tongue and grooved chipboard
Direct-to-Timber System RTC 014
1x 12.5mm Siniat E Board,1x 12.5mm Siniat E Board,100mm 10.5kg/m3 glass mineral wool,47mm x 200mm joists at 450mm centres without noggins,22mm tongue and grooved chipboard
Suspended MF System PGC 202
1x Siniat Creason R15no1, Siniat MF Ceiling Channels at Max 450mm centres, Siniat Connecting Clips, 30mm glass mineral wool and 50mm void, Any suitable soffit
Suspended MF System PGC 003
1x Siniat Creason C10no8, Siniat MF Ceiling Channels at Max 450mm centres, Siniat Connecting Clips, 50mm glass mineral wool and 300mm void, Any suitable soffit
